Gansu customer two sets of rake dryer delivery

National Day is coming. I wish you a happy National Day! Two sets of rake dryer renewed by an old customer of a pharmaceutical factory in Gansu Province were loaded and delivered today. At present, the equipment has been successfully delivered. Recently, our staff will arrive at the customer's site for installation and commissioning! The working principle of rake vacuum dryer is mainly composed of shell, rotating shaft and rake teeth. And pulp leaf dryer different, vacuum rake dryer of

National Day is coming. I wish you a happy National Day!

Two sets of rake dryer renewed by an old customer of a pharmaceutical factory in Gansu Province were loaded and delivered today. At present, the equipment has been successfully delivered. Recently, our staff will arrive at the customer's site for installation and commissioning!

Working principle of rake vacuum dryer

Vacuum rake dryer is mainly composed of shell, rotating shaft and rake teeth. Different from the paddle dryer, the rotary shaft and rake teeth of the vacuum rake dryer are not used as heating surfaces, they are only used to stir materials and renew the surface. The rake dryer is vacuum operated. Firstly, the wet materials are added into the dryer, and the heating medium (usually steam or hot water can also be used as heat transfer oil) is introduced into the jacket. Then, the vacuum pump is started. After reaching the specified vacuum degree, the mixing device is started. By using the forward and reverse rotation of the rake teeth, the materials are continuously pushed to the middle and both ends in the drying process Four stainless steel bars (seamless steel tubes) can also be placed according to the user's requirements. They move up and down continuously during the rotation of the shaft, vibrate the materials bonded on the wall and crush the agglomerated materials. Through these measures, the heat transfer surface can be updated in time, thus accelerating the rate of heat and mass transfer. When the material is dried to the specified moisture, stop heating, turn off the vacuum system, take out the dried material, and complete the operation of one cycle. This kind of dryer is suitable for the drying of pulp, paste, granular and fibrous materials, especially for the drying operation of heat sensitive materials and the recovery of organic vapor. The vacuum rake dryer has many advantages. There are two basic forms of rake teeth of vacuum rake dryer, i.e. left and right rake teeth. There are two kinds of special-shaped and pulp blade types in both left and right directions. When installing, the orientation difference between adjacent rake teeth is 90 degrees. The special-shaped rake teeth are installed at both ends of the shaft, and the rest are installed with pulp blade type rake teeth. When the shaft rotates, the material moves to both sides first and then to the middle under the action of the mixing shaft, which can ensure that the material is always in a uniform mixing state in the whole drying process.

The commonly used drying medium of vacuum rake dryer is 0.1-0.3mpa steam, heat-conducting oil or hot water. The vacuum degree in the dryer is 50-90kpa, the material filling rate is 30% - 80%, and the thermal efficiency is 70% - 80%. The shaft speed is 6-30rpm stepless speed regulation.

Characteristics of rake dryer

① This machine adopts the heating mode of interlayer and internal stirring at the same time, with large heat transfer surface and high thermal efficiency.

② This machine is equipped with stirring to make the material form continuous circulation state and further improve the uniformity of material heating.

③ This machine is equipped with stirring, so that the slurry, paste and paste materials can be dried smoothly.

④ The machine adopts mechanical seal, which can control the vacuum degree of equipment well.

Application range of vacuum rake dryer

Pharmaceutical, food, chemical and other industries to dry materials

Paste, paste and powder materials

Heat sensitive materials requiring low temperature drying

It is easy to oxidize, explosive, strong stimulation and highly toxic materials

Materials requiring recovery of organic solvents.   

Features of ZPG vacuum rake dryer:   

The heat transfer surface is large and the thermal efficiency is high.   

Mixing is set to make the material form a continuous circulation state in the cylinder, which further improves the heating uniformity of the material.   

Set up stirring, so that the slurry, paste and paste materials can be dried smoothly
